Are you looking for an out of production item, or need a customization?
Details
ISO thread DIN 13 coarse pitch
Tolerance: 6HX
Surface finish: TiCN
Thread depth: ≤ 2XD
Hole type: Blind and through
Chamfer form: C 2/3
Application: Grey cast iron and aluminum alloys with silicon ≥ 10%
Tolerance: 6HX
Surface finish: TiCN
Thread depth: ≤ 2XD
Hole type: Blind and through
Chamfer form: C 2/3
Application: Grey cast iron and aluminum alloys with silicon ≥ 10%
Recommended cutting data i
Specifications
CARBON STEEL
< 500 N/mm²
< 850 N/mm²
< 1200 N/mm²
STAINLESS STEEL
< 600 N/mm²
< 850 N/mm²
Duplex
CAST IRON
< 240 HB
< 300 HB
NON FERROUS
< 10% Si
> 10% Si
Brass Copper
Bronze
SUPER ALLOY
Ti6Al4V
HTA
HARDENED
< 45 HRC
< 60 HRC
-
Standard DIN 371-376
-
Ring colour white
-
Blind and through holes
-
TiCN
-
M thread
-
Profile 60°
- Product code
- A2320
- Brand
- KERFOLG
